Product Details

• Basic Information




  manufacturer	Dongfeng Motor
  brand	Dongfeng Xiaoduolika
  Vehicle Type	Water Tank Fire Truck
  Engine horsepower	132 HP
  Engine power (KW)	97
  Energy type	Diesel
  Emission standard	China VI
  Tire Specification	7.00R16LT 14PR
  Cabin Capacity	2/3 people
  Top speed (km/h)	110
  Length x Width x Height (mm)	6230*2030*2720
  Vehicle model	KLF5070GXFSG25/E6A



  Wheelbase (mm)	3308
  Tank Capacity	2500L
  Fire Pump	CB10/20
  Fire Cannon	PS8/20
  Fire Cannon Range	Water ≥ 50m
  Curb weight (kg)	4075
  Maximum total mass (kg)	6950
  Rated load weight（kg）	2500
  Front/Rear Overhang (mm)	1040/1662
  Approach/Departure Angle(°)	24/14
  Axle Load (kg)	2230/4720
  Alarm Light	1.2m LED beacon on top of the cabin




• Product Positioning




• Application Scenarios

  Fire Suppression
  Capable of undertaking initial fire control tasks in residential areas, building fires, and commercial complexes. The cab roof is equipped with a 1.2-meter-long LED light bar, the rear top of the vehicle features a 45W LED firefighting spotlight with 360° remote-controlled rotation, and a foldable ladder is installed at the rear, which can facilitate rapid and efficient fire control measures.
  Industrial Zone Rescue
  Designed for special environments such as petrochemical plants and hazardous material warehouses, it provides chemical dilution capabilities and emergency water supply for industrial accidents. The pipeline system is constructed with high-quality seamless steel pipes, including:
  A DN100 tank outlet pipeline (water flows from the tank to the fire pump) with a manual butterfly valve and DN100 flexible connector
  An external intake pipeline with a threaded KA100 sealed suction inlet (compatible with 100mm suction hoses) for efficient water transfer.
  Forest & Grassland Fire Control
  The large-capacity water tank enables remote water supply. Firemen can establish a mobile water hub at the fire perimeter to address wildland water shortages. It supports direct water intake from natural sources (lakes, rivers) via a high-power pump. Multiple trucks can form a water relay chain to sustain frontline firefighting equipment (e.g., fire monitors, helicopter buckets).
  Natural Disaster Response
  Executes flood drainage, emergency water supply for displaced victims, and road cleaning during floods/earthquakes. Equipped with globally standardized firefighting technology:
  Fire pump performance: Flow rate 20L/s, pressure 1.0MPa, max suction depth 7m, priming time ≤35s, can effectively extinguish fire, featuring high working efficiency and fast response speed, minimize disaster losses to the greatest extent.
