Product Details

• Basic Information




  manufacturer	Dongfeng Motor
  brand	Dongfeng Duolika D7
  Vehicle Type	Compression garbage truck
  Engine model	YCY30165-60
  Engine power (KW)	121
  Energy type	Diesel
  Emission standard	China VI
  Tire Specification	245 Tubeless Tires
  Fuel Consumption	20.3
  Top speed (km/h)	103/89
  Length x Width x Height (mm)	7350/7537/7450*2280/2400*2780/3200
  Vehicle model	KLF5120ZYSE6



  Wheelbase (mm)	3800
  Operation Mode	Electric Control / Manual / Remote Control
  Loading Cycle Time	12—25S
  Unloading Time:	≤60S
  Effective Compartment Volume (m3)	10.5
  Curb weight (kg)	6500/6824/7140
  Maximum total mass (kg)	11995
  Rated load weight（kg）	5300/4976/5365/5041/4660/4725
  Rear equipment	Standard: flip plate,optional: triangular bucket, ground bucket, swing arm
  Compartment Material	High-Strength Manganese Steel Plate
  Compression Ratio	better than 1：2.5
  Standard functional configuration	Night work lights, dual wastewater tanks, drainage pipe

• Product Positioning




• Application Scenarios

  Waste Collection
  Equipped with hydraulically driven mechanical arms, tipping mechanisms, or manual feed ports, it enables efficient waste collection and transportation in various settings—including industrial plants, underground garages, power stations, parks, streets, residential communities, and rural towns. It accommodates both standard waste bins and loose garbage.
  High-Efficiency Compression
  Utilizing market-proven hydraulic transmission, electrical control, and bidirectional compression technology, the automated system ensures waste dumping, powerful compaction, and dual-direction loading. With advantages such as high pressure, superior sealing, user-friendly operation, and reliable stability, it achieves a compression ratio better than 1:2.5 and a single-cycle time ≤20 seconds, enhancing waste collection efficiency.
   Enclosed Transportation
  The streamlined arc-shaped body is formed in one pass by a four-axis rolling machine, eliminating spillage and odor leakage during transit. Its sleek design enhances structural integrity, resists deformation, and maximizes usable volume—exceeding competitors. Constructed from high-strength manganese steel plates, it offers exceptional durability, wear resistance, and corrosion resistance.
  Automated Unloading
  The intelligent control system adopts CAN bus technology with a modular structure. It supports manual, automatic, and semi-automatic operation modes, and can use remote control to operate the driver’s cabin, front, or rear of the body for adaptable performance in diverse situations.
