Product Details

• Basic Information




  manufacturer	Huashen Automobile
  brand	Huashen KL5
  Vehicle Type	Water sprinkler truck
  Engine model	YCY30165-60/D30TCIF1/YCS06200-68
  Engine power (KW)	121/125/147
  Energy type	Diesel
  Emission standard	China VI
  Working speed	1500r/min for the engine
  working process	Standardize 14 procedures
  Coating process	Electrophoresis process
  Length x Width x Height (mm)	7700*2500*3200（Optional）
  Vehicle model	KLF5161GSSE6



  Wheelbase (mm)	3950
  water inlet pipe	Φ89,with a large water inflow
  Rooms of the water tank	2 to 3 rooms
  Effective volume of the tank (m3)	9.56
  Material	High-quality carbon steel(4MM thick)
  Curb weight (kg)	5675；6240
  Maximum total mass (kg)	16000
  Width of the front flush water	15 to 30 meters
  Rear platform water-spraying cannon	360 degrees adjustable
  Water pump	High-power water pump, vertical suction lift 6 meters
  Bottom drainage outlets	2 outlets
  Standard functional configuration	Side spray, S-shaped water cannon and fire coupling




• Product Positioning




• Application Scenarios

  1. Municipal Sanitation
  The water sprinkler truck is designed for professional environmental cleaning operations. Equipped with a customized high-power water pump, it delivers outstanding performance, reliable operation, high efficiency, and large flow capacity. Its front-flushing system can cover 8 lanes bidirectionally, while the rear sprinkler reaches 4 lanes bidirectionally, enabling highly efficient road washing and dust suppression.
  2. Greening Maintenance
  The water sprinkler truck serves as a "mobile irrigation station" for urban landscaping. Its Φ89-mm water intake pipe ensures fast refilling, significantly reducing downtime and boosting productivity. The truck features multi-directional front flushing, fan-shaped rear sprinkling, a rear-mounted high-pressure cannon, and side sprays. Optional add-ons include overhead sprinklers, electronic cannons, and adjustable duckbill nozzles, making it adaptable to diverse scenarios with precision and efficiency.
  3. Firefighting Support
  This sprinkler truck can provide emergency water supply before fire engines arrive. Its high-pressure cannon achieves a maximum range of 40 meters, allowing it to control initial fires and cool down high-temperature zones after extinguishing flames.
  4. Industrial & Construction Applications
  The truck effectively suppresses dust at construction sites and mines. Its tank and sub-frame are securely connected via reinforced bolt-on plates, ensuring stability and safety even on rough terrains or bumpy roads. This design prevents tank displacement, enhancing structural integrity and operational safety
