Product Details

• Basic Information




  manufacturer	HOWO Truck
  brand	HOWO 12T
  Vehicle Type	Truck-mounted Crane
  Cargo Box Dimensions	7600,8000,8200,8300,8400×2400,2450×600,550(mm)
  Cabin Capacity	2 people
  Energy type	Diesel
  Boom	12-ton, 5-section boom
  Tire Specification	11.00R20 18PR,12.00R20 18PR
  Front Wheel Track (mm)	2011/2011,2036/2036,2070/2070(mm)
  Rear Wheel Track (mm)	1860/1860(mm)
  Length x Width x Height (mm)	12000×2500,2550×3780,3980(mm)
  Top speed(km/h)	89



  Wheelbase (mm)	2100+5775+1400
  Lifting Height	20.75 meters
  Working Radius	18.75 meters
  Leaf Spring Number	14/14/12, 10/10/10
  ABS (Anti-lock Braking System)	Yes
  Curb weight (kg)	20800,19900(Kg)
  Maximum total mass (kg)	31000
  Rated load weight（kg）	10070,10970(Kg)
  Front Overhang (mm)	1525
  Rear Overhang (mm)	2400
  Approach Angle	16°
  Departure Angle	10°

• Product Positioning




• Application Scenarios

  Material Handling & Cargo Transport
  High-efficiency Loading/Unloading: Ideal for heavy cargo like construction materials (steel pipes, precast concrete) and machinery, with a single lift capacity up to 12 tons, reducing reliance on forklifts/cranes.
  Flexible Operation: Features 360° full-rotation boom, adapting to confined spaces in warehouses/ports for container handling and production line material transfer.

  Municipal Engineering & Emergency Repair
  Power/Telecom Maintenance: Aerial lifting of streetlight poles and signal tower components (max height 20.75m, working radius 18.75m) for rapid equipment repair.
  Pipeline Installation: Precise placement of large-diameter drainage/gas pipes to enhance urban construction efficiency.

  Emergency Rescue & Disaster Response
  Accident Recovery: Rapid clearance of overturned vehicles/collapsed structures, assisting fire departments in disaster-site equipment relocation.
  Post-Disaster Reconstruction: Debris removal and temporary housing assembly, supporting critical route restoration.

  Specialized Industry Applications
  Forestry Operations: Timber and forestry machinery handling in mountainous terrain.
  Oilfield/Wind Power: Modular lifting of oilfield equipment/wind turbine components (requires customized heavy-duty models)
